The auto plaster machine transforms plastering work from a labor-intensive craft into a standardized, industrialized, and precise process through the integration of intelligent sensing and automatic control technology.【WhatsApp/WeChat/Phone】+86 13837122632
Wall Cement Plaster Machine Parameters
| voltage | DC48V |
| power supply mode | battery |
| Standard battery capacity | 30AH |
| Mechanical arm size (length * width * height) mm | 242*120*1800 |
| Host size (length * width * height) mm | 700*550*1050 |
| Overall dimension (length * width * height) mm | 850*550*1850 |
| Spatula length m | 1.3 meters |
| Smoothing height m | 3 meters, 4 meters, 5 meters, 6 meters |
| Total weight Kg | one hundred and eighty |
Why Can the Auto Plaster Machine Eliminate the Need for Setting Guide Strips?
“Setting guide strips and spotting” is the core preparatory step in traditional plastering to ensure flatness. It is time-consuming, labor-intensive, and places high demands on workers. This auto plaster machine can omit this step, thanks to its secrets lying in a closed-loop intelligent leveling system:
- Real-Time Sensing Replaces Manual Calibration: The attitude sensor at the top of the device acts like a “high-precision eye,” scanning the relative state between the wall and the mechanical arm in real-time with resolution far exceeding the human eye. It performs multiple data acquisitions per second, replacing the reference function of physical “guide strips.”
- Intelligent Decision-Making Replaces Experienced Judgment: The built-in logic programmer serves as the “brain,” calculating deviations in real-time based on sensor data and instantly making adjustment decisions. Its accuracy and consistency far surpass those of experienced masters relying on skill.
- Servo Execution Replaces Manual Adjustment: System commands drive the high-precision attitude adjustment mechanism and servo motors, automatically regulating the trowel to an absolutely vertical and horizontal state. The entire process is fully automated, eliminating human error at its root, thus eliminating the need for pre-setting guide strips.
Breakthroughs in Precision and Stability by the Auto Plaster Machine
Compared to the inevitable fatigue and performance fluctuations of manual operation, this automatic wall plastering machine achieves a dimensional leap in precision and stability:
- Millimeter-Level Precision Assurance: Its high-precision attitude adjustment system, combined with a 1.3-meter-wide trowel, ensures minimal flatness error across the entire working surface. The verticality of inside and outside corners far exceeds acceptance standards, achieving “industrial-grade” construction quality.
- Consistent and Stable Output: The machine does not suffer from fatigue. It can operate continuously and stably under battery power. Regardless of how long it works, the quality of its output remains consistent, completely solving the problem of declining manual construction quality over time and due to physical exertion.
- Adaptability to Complex Working Conditions: The self-adaptive chassis system effectively counteracts the effects of slight ground unevenness, ensuring machine stability. The wheeled mobility design allows it to operate flexibly in narrow spaces, an advantage in maneuverability that manual scaffolding can hardly match.
How Does the Auto Plaster Machine Help Reduce Costs and Increase Efficiency?
Introducing an auto plaster machine is not just an equipment upgrade; it’s a profound transformation in construction economics. Its comprehensive benefits are reflected across multiple levels:
- Sharp Reduction in Direct Labor Costs: A single machine can cover hundreds of square meters per day, replacing a team of skilled workers. This significantly reduces labor requirements and management costs, alleviating the pressure of “labor shortage.”
- Significant Shortening of Overall Project Timeline: It eliminates the time needed for setting guide strips and repeated verification. Coupled with extremely high operational efficiency, it accelerates the flow of critical project phases, shortens the overall project timeline, enables earlier inspection/payment, and improves capital turnover.
- Optimization of Material and Management Costs: High-precision construction greatly reduces mortar rework and waste caused by failing to meet flatness standards. Standardized operation reduces dependence on specially skilled workers and simplifies on-site management complexity.
- Long-Term Investment Value: The equipment is robust and durable and supports IoT remote upgrades and maintenance, ensuring it remains at the technological forefront long-term. For companies or individuals frequently engaged in plastering projects, it is a house plastering machine that can quickly recoup costs and a strategic asset that enhances core competitiveness.
Contact Us
Welcome to contact us at any time for professional services regarding intelligent plastering equipment:
- Professional Solution Consultation: We will recommend the most suitable house plastering machine model or a customized solution based on your specific construction needs (e.g., batch plastering for residential projects or large-scale engineering).
- Schedule an On-Site Demonstration: We can arrange for you to inspect the actual working effect of the automatic wall plastering machine on-site, allowing you to intuitively experience its efficiency and precision.
- Obtain Complete Support: From procurement to long-term after-sales service, we provide one-stop support to ensure your wall cement plaster machine operates stably and maximizes your return on investment.【WhatsApp/WeChat/Phone】+86 13837122632
