The automatic tapping machine is specially designed for machining internal threads on a wide range of materials such as metals, plastics, and wood. It cuts threads in pre-drilled holes by rotating a tap. The thread tapping machine goes a step further by automatically completing operations such as feeding the tap, controlling the thread depth, and reversing the exit tap, which greatly improves processing efficiency. We also produce rebar couplers, rebar forging machines, rebar rolling machines, rebar straightening and cutting machines, and so on. Which machine do you want? Contact us immediately!
Automatic Tapping Machine Parameters
| SPECIFICATION | YG-20/40 | YG-25/50 | YG-30/60 |
| TAPPING CAPACITY IN STEEL | 6-20mm coarse pitch, 6-40mm fine pitch | 6-25mm coarse pitch, 6-50mm fine pitch | 10-30mm coarse pitch, 10-60mm fine pitch |
| SPINDLE DIAMETER | 30mm | 35mm | 40mm |
| SPINDLE TRAVEL MAX. | 110mm | 110mm | 125mm |
| COLUMN DIAMETER | 100mm | 100mm | 110mm |
| DISTANCE B/W SPINDLE CENTER TO COLUMN | 216mm | 216mm | 250mm |
| TABLE SHAPE | Rectangular | Rectangular | Square |
| TABLE SIZE (LxB) | 405x225mm | 405x225mm | 760x590mm |
| WORKING AREA | 330x150mm | 330x150mm | 620x260mm |
| FLOOR AREA(LxB) | 1220x760mm | 1220x760mm | 1400×620 |
| NO. OF SPEEDS | 2 AC Drive Optional | 2 AC Drive Optional | AC Driver |
| MOTOR REQUIRED | 2 HP/1440 rpm | 2 HP/1440 rpm Or 2 HP/900rpm | 3 HP/1440 rpm |
| TOTAL HEIGHT | 1900mm | 1900mm | 2100mm |
| TOTAL WEIGHT | 350kg.(approx) | 400kg.(approx) | 550kg.(approx) |
| MAX. TAP SHANK THAT CAN BE BEHOLD IN THE TAP HOLDER | 20mm | 30mm | 40mm |
| COMPLETE BELT COVER | YES | YES | YES |
| MOTOR COVER WITHIN MACHINE FRAME | YES | YES | YES |
| COOLANT SYSTEM | YES | YES | YES |
| COUNTER METER | YES | YES | YES |
| SAFETY CUT-OFF LIMIT SWITCHES | YES | YES | YES |
| PHASE PREVENTER | YES | YES | YES |
| COOLANT TANK CAPACITY | 40 Liters | 40 Liters | 40 Liters |
| VARIOUS PITCH SIZES CAN BE DONE | METRIC PITCH 0.8,1.0,1.25,1.5,1.75, 2.0,2.5 UNIFIED PITCH(tpi) 26,24,20,19,18,16,14 12 | METRIC PITCH 1.0,1.25,1.5,1.75, 2.0,2.5,3.0,3.5 UNIFIED PITCH(tpi) 24,20,19,18,16,14 12,11 | METRIC PITCH 1.0,1.25,1.5,1.75, 2.0,2.5,3.0,3.5,4.0 UNIFIED PITCH(tpi) 24,20,19,18,16,14 12,11,10,8 |
| STANDARD EQUIPMENT | Floating Tap holder 2no., 2no. Tap collets of any size, 2no. Lead Screw (Fitted), spanners, LN keys | Floating Tap holder 2no., 2no. Tap collets of any size, 2no. Lead Screw (Fitted), spanners, LN keys | Floating Tap holder 2no., 2no. Tap collets of any size, 2no. Lead Screw (Fitted), spanners, LN keys |
Applications of Thread Tapping Machine
- In automobile manufacturing, thread processing of engine block, gearbox shell, and other key components.
- In the aerospace field, for the thread processing of aircraft;
- Aerospace industry, to process high-precision threads for airplane parts;
- In the electronics industry, threads can be machined on small parts such as circuit boards.
- Furniture manufacturing, also used for thread processing required for wooden furniture assembly.
- New energy automobile: the battery pack shell needs hundreds of M3 threaded holes, the fully automatic model can complete 5000 in 8 hours.
- Medical devices: implant-grade titanium alloy screw hole processing, the error must be controlled within 0.008mm;
- Smart home: smart lock body tapping with a CNC drilling and tapping machine to realize the integration of drilling and tapping.
Features of the Automatic Tapping Machine
- High precision: cnc drilling and tapping machine can process high-precision threads to ensure the perfect fit of screws and bolts, which is indispensable in aerospace, medical equipment and other industries that require strict tolerances.
- High efficiency: Compared with manual processing, thread tapping machines are faster, significantly reducing production time and costs. Some models can also process multiple holes at the same time, significantly increasing production capacity.
- Multi-functional: It can be adapted to a variety of materials and tap sizes to meet different application scenarios. They can also be programmed to process a wide range of thread types, including metric and inch.
- Easy to Operate: Most of the cnc tapping machines adopt a user-friendly operation interface, which makes it easy for novices to get started. Equipped with touch screen control, preset programs, automatic error detection, and other functions.
Working Principle of CNC Tapping Machine
The working principle of the automatic tapping machine is not complicated. Drill a good hole in the workpiece first, insert the tap, and the motor drives the tap to rotate and cut the thread. The feeding mechanism controls the tap in and out to determine the depth of the thread. After cutting is completed, the tap reverses and exits. Part of the equipment is also equipped with a cooling system to cool and lubricate the tap, prolonging the service life and improving the thread quality.
How to Select the Right CNC Drilling and Tapping Machine?
- Clear demand: consider the processing material, the size and number of holes, and precision requirements, to determine the appropriate model.
- Focus on function: pay attention to the speed of the equipment, the number of spindles, the type of control system, and automation functions, which will affect the efficiency and convenience of use.
- Check the quality: equipment with high-quality materials and solid construction is more reliable and durable, so check carefully when selecting.
- Reference and comparison: research different brands and models, read user reviews to understand performance, compare prices and features, and select a cost-effective product.
Automatic Tapping Machine for Sale- YG Machinery
When looking for a reliable automatic thread tapping machine, YG is a good choice, a well-known manufacturer specializing in high-quality thread tapping machines that are known for their high accuracy, efficiency, and durability, with a wide range of models to suit different needs and budgets. The automatic thread tapping machine, or thread tapping machine, has become a highly sought-after machine in the industry. It has revolutionized the way threads are machined on all types of materials, making the process faster, more accurate, and significantly reducing labor costs.
