The concrete pump mixer truck perfectly integrates mixing and pumping functions, easily handling various complex construction environments while saving significant time and labor costs for engineering projects. If you’re looking for equipment that enhances efficiency and reduces operational expenses, YG’s concrete mixer and pump truck is your ideal choice. Feel free to contact us anytime for more product information!【WhatsApp/WeChat/Phone】+86 13837122632
Concrete Pump Mixer Truck Parameters
| System Type | Parameter Name | Unit | Value |
| Pumping System | Max. Theoretical Pumping Capacity | m³/h | 110 |
| Max. Outlet Pressure | MPa | 8.5 | |
| Theoretical Pumping Frequency | times/min | 25 | |
| Hydraulic System Pressure | MPa | 32 | |
| Delivery Cylinder Diameter | mm | 230 | |
| Delivery Cylinder Stroke | mm | 1400 | |
| Delivery Pipe Diameter | mm | 125 | |
| Hydraulic Oil Cooling Method | – | Air Cooling | |
| Pumpable Concrete Slump | mm | 160–220 | |
| Max. Aggregate Size | mm | 40 | |
| Hydraulic System Type | – | Open System | |
| Mixing System | Mixer Type | – | Forced Mixer |
| Productivity | m³/h | 25–35 |
Advantages of Concrete Pump Mixer Truck
- Outstanding Mobility:
This truck mounted concrete pump features a compact design with a total length of 10.8m, height of 3.85m, and wheelbase of only 4.4m. Its excellent maneuverability allows easy operation even on narrow rural roads, perfectly solving the transfer difficulties of traditional equipment. - High Pumping Efficiency:
Equipped with a large-displacement pumping system and a forced mixer, it delivers 0.75m³ per batch and 30m³ per hour. The maximum theoretical pumping capacity reaches 110m³/h. The powerful performance ensures the concrete boom pump truck maintains stable output under various conditions, while its ability to handle mixed aggregate further enhances practicality. - Smart Energy-Saving Technology:
The innovative system automatically matches pumping displacement with engine power, reducing fuel consumption by 10%. The mixer supports three-phase power connection and is equipped with a generator for field operations. The electric control system connects with a cloud platform, making equipment management smarter and more efficient.
Concrete Pump Mixer Truck Applications
This unit can both mix and pump concrete on-site or deliver ready-mixed concrete with a capacity of up to 90m³/h. When working in confined areas or places beyond the boom’s reach, the rear pipeline allows it to operate as a truck-mounted pump with a maximum horizontal pumping distance of 300m. The flexibility of this concrete mixer and pump truck enables it to handle anything from large commercial projects to small rural constructions with ease.
Case Study
Last year, we supplied several concrete pump mixer trucks to a rural infrastructure project in British Columbia, Canada. Located in mountainous terrain with narrow roads, traditional concrete equipment could not access the site. Our trucks, with excellent maneuverability and strong pumping capacity, solved this challenge perfectly. The client highly appreciated the all-in-one design that enables both on-site mixing and pumping of ready-mixed concrete, greatly improving efficiency. The concrete boom pump truck’s outstanding performance earned high praise from Canadian customers.
6 Reasons to Choose YG
1. Leading Innovation:
YG pioneers advanced technologies such as the nation’s first hydraulic lifting hopper, replacing the traditional steel rope design for easier, maintenance-free operation.
2. Compliance and Safety:
All equipment meets strict regulatory standards. The perfect integration of mixer and pump ensures legal road use without overweight issues, saving up to one hour per transfer.
3. Proven Global Experience:
With years of industry expertise, YG products are used in dozens of countries for residential, road, and water conservancy projects.
4. Customized Solutions:
YG provides tailored services to meet each client’s specific project needs, ensuring every truck mounted concrete pump fits perfectly.
5. Exceptional Cost Efficiency:
Compared with buying separate mixer and pump vehicles, choosing YG’s concrete mixer and pump truck saves about 30% in overall cost, offering excellent ROI.
With advanced technology and rich industry experience, YG provides customers with top-quality equipment and service. Whether for compact job sites or large-scale projects, YG’s concrete pump mixer truck delivers the perfect solution. Choosing YG means choosing reliability, efficiency, and innovation.
Contact us now for a free quote and customized plan!【WhatsApp/WeChat/Phone】+86 13837122632
