The GRC machine is the “efficiency tool” of the modern construction industry. Through high-pressure spraying, it evenly adheres glass fibers and concrete mixture to molds or wall surfaces, rapidly forming high-strength decorative components. From European-style architectural lines to shaped landscape sculptures, the GRC spray machine makes complex designs easy to implement and shortens the construction period by more than 50%.
GRC Machine Parameters
| Product name | Glass Fiber Reinforced Concrete GRC Spray Machine |
| Power | 2.2-4.0kw |
| Voltage | 380v 50hz |
| Speed | 20-200r/min |
| Workspace | 4.5m |
| Delivery capacity | 300-1600kg/h |
| Production efficiency | 200-400m2/h |
| Volume | 60L |
| Dimension for the sprayer | 2000*1050*1600mm |
| Dimension for the mixer | 1550*1000*2100mm |
| Total weight | 800kgs |
Wide Range of Applications for GRC Spray Machine
The GRFC spray machine has a wide range of applications.
- In exterior decoration, it can create a variety of beautiful shapes and textures to add character to a building’s appearance. For interior decoration, it can be used to make decorative lines, fireplaces, etc., to enhance the quality of interior decoration.
- In landscape gardening, it can be used to build exquisite vignettes, fountains, flower pots, and so on.
- Even for the restoration of monuments, GRC components can be used to faithfully restore damaged building parts.
Working Principle of the GRFC Spray Machine
- When the GRC Machine is in operation, the mixing system accurately proportions the raw materials such as cement, sand, fiberglass, and water.
- Then, the mixing device mixes the raw materials evenly.
- The mixed materials are sent to the mold through the conveying system.
- During the molding process, different shapes and sizes of GRC products can be made according to requirements.
- Finally, the products undergo a curing process to improve their strength and stability.
Advantages of the YG Machinery GRFC Machine
As a professional manufacturer of GRFC machines, YG Machinery has significant advantages.
- High production efficiency, can quickly produce a large number of high-quality GRC products, and shorten the project time.
- The quality of the products is excellent, with high strength, good toughness, impact resistance, smooth and delicate surface, and tight internal structure.
- Easy to operate, reducing the labor intensity of workers. In addition, the equipment is stable and reliable, low maintenance cost, and can run stably for a long time.
Parameter Structure of GRC Machine
- The foundation frame part, welded with high-strength steel, provides stable support for the whole machine.
- The mixing system includes the mixing drum, mixing blades, and drive motor. The mixing barrel is made of special wear-resistant material to prolong the service life.
- The conveying system consists of pipes, conveying pumps, and control valves. The pipeline is made of wear-resistant rubber material. The conveying pump can adjust the flow rate and pressure according to the production demand.
- The molding system consists of molds, a vibration unit, and a demolding mechanism.
- The control system includes a touch screen and sensors. The touch screen allows the operator to perform simpler operations.
GRC Spraying Machines Manufacturer- YG Machinery
GRC Machine is the key equipment for producing complex GRC products, which can make glass fiber reinforced concrete evenly sprayed and formed. Compared with the traditional process, it is not only 50% more efficient, but also can accurately render complex textures and curved designs, which greatly broaden the creative boundaries of architectural decoration.
YG also provides high standards of manufacturing processes and comprehensive services, from installation and commissioning to technical training, and from after-sales maintenance to spare parts supply. Choosing YG Machinery’s GRC sprayers means choosing a professional and reliable production partner, allowing architectural ideas to be realized efficiently! We also provide polyurethane sprayers, mortar sprayers, concrete mixers, concrete pumps, wall plastering machines, etc. Click for more info!
