Road rollers, also known as road roller machines in English, are key equipment for road construction and maintenance. They can compact various types of pavement materials and improve the stability and bearing capacity of the road surface. Common road rollers include small mini road pavement rollers and large road construction rollers. Small road rollers are flexible and convenient and perform well in narrow spaces and small projects; large road rollers are powerful and suitable for large-scale road construction.
Road construction rollers parameter
| Model | YG-600S | YG-880 | YG-850 | YG-880 |
| Power | 5.5HP | 25HP/20HP | 6.0HP | 25HP/20HP |
| Walk Speed | 2.4km/h | 0-5KM/H | 0-4km/h | 0-5KM/H |
| Climbing Capacity | 25% | 30% | 30% | 30% |
| Static Linear Load | 45n/cm | 45n/cm | 45n/cm | 45n/cm |
| Exciting Force | 20KN | 50KN | 20KN | 50KN |
| Vibration Frequency | 70HZ | 70HZ | 70HZ | 70HZ |
| Drive | Hydraulic Drive | Hydraulic Drive | Hydraulic Drive | Hydraulic Drive |
| Water Tank | 15L | 15L | 15L | 15L |
| Hydraulic Oil Tank | 3.6L | 19L | 3.6L | 19L |
| Engine Model | HONDA GX160 | GX390 | HONDA GX270 | GX390 |
| Steel Wheel Size | 426x600mm | 800x850mm | 580x700mm | 800x850mm |
| Package Size | 1050x900x1200mm | 2100*1000*1650 mm | 1550x900x1200mm | 2100*1000*1650 mm |
| Weight | 330kg | 1000kg | 750kg | 1000kg |
Structure of road roller machine
Different types of road rollers have slightly different structures, but they are composed of engines, transmission systems, rolling devices, operation control systems, etc.
- Engine: Provides power for the roller, and common ones are diesel engines and gasoline engines. Diesel engines are powerful and suitable for large rollers; gasoline engines are easy to start and are more commonly used in small rollers.
- Transmission system: Transmits the power of the engine to the rolling device and walking device to ensure the normal operation of the roller.
- Rolling device: The core part, including steel wheels, tires, etc. Single steel wheel roller compacts with the front steel wheel; double steel wheel roller works with the front and rear steel wheels; tire roller applies pressure through the tire.
Operation control system: It is convenient for operators to control the speed, direction, and compaction strength of the roller.
Road roller machine price
Road roller machine varies greatly due to different models, configurations, and manufacturers. Small mini road pavement rollers are relatively cheap, while large road construction rollers are more expensive. As a high-quality roller manufacturer, YG insists on using high-quality materials, using advanced production processes, reducing production costs, and providing customers with high-quality and low-cost rollers, helping customers save costs and create greater value.
Choosing a suitable pavement roller
When choosing a roller, it is necessary to comprehensively consider factors such as the scale of the construction project, site conditions, and pavement materials.
- Construction project scale: For small projects, such as sidewalks and courtyard construction, mini road pavement rollers are selected, which are flexible and economical; for large road construction projects, large road construction rollers are used to improve construction efficiency.
- Site conditions: For narrow spaces, small rollers are more suitable; for open sites, large rollers can be selected.
- Pavement materials: For compacting asphalt pavement, double-wheel rollers are effective; for compacting soil and gravel, single-wheel vibratory rollers are more suitable.
YG is a high-quality roller machine for road construction manufacturer
YG has focused on the research and development, production, and sales of rollers for many years and has accumulated rich experience. We have a professional R&D team and continuously introduce new technologies and processes to improve product performance. During the production process, we strictly control quality to ensure that every road roller machine meets high standards. In addition, YG also provides comprehensive after-sales service to promptly solve problems encountered by customers during use. Choosing a YG roller means choosing high quality, high performance, and comprehensive service guarantees.
