When heavy rain turned Johor’s construction sites into muddy swamps, contractor Mr. Amir’s project came to a halt. It was during this crisis that he discovered YG’s front end loader excavator — a versatile machine combining front loading and back digging functions. Not only did it save his project, but it also demonstrated the true value of “one machine for multiple tasks.”【WhatsApp/WeChat/Phone】+86 13837122632
Front End Loader Excavator Parameters
| Main Specifications | Operating Weight | 7,500 kg |
| L*W*H | 7,600*2,260*2,900 mm | |
| Wheel base | 2,250 mm | |
| Wheel Tread | 1,700 mm | |
| Min. Ground Clearance | 300 mm | |
| Hydraulic System Pressure | 22 Mpa | |
| Hydraulic System Flow | 120 L/min | |
| Max. Traction | 39 kN | |
| Loader Performance | Rated Load | 2,500 kg |
| Loader Bucket Capacity | 1.3 m³ | |
| Loader Bucket Width | 2,100 mm | |
| Loader Bucket Dumping Height | 2,742 mm | |
| Loader Bucket Dumping Distance | 1,062 mm | |
| Loader Bucket Digging Depth | 52 mm | |
| Loader Bucket Breakout Force | 38 kN | |
| Loader Bucket Lifting Time | 5.4S | |
| Loader Bucket Lowering Time | 3.1S | |
| Loader Bucket Discharging Time | 2.0S | |
| Backhoe Performance | Backhoe Bucket Capacity | 0.3 m³ |
| Backhoe Bucket Width | 600 mm | |
| Max. Digging Depth | 4,082 mm | |
| Backhoe Digging Force | 46.5 kN | |
| Backhoe Boom Digging Force | 31 KN | |
| Backhoe Bucket Swing Angle | 180° | |
| Engine | Brand & Model | YUCHAI |
| Type | In Line, Direct injection, 4-Stroke, Water-cooled, Diesel | |
| Rated Power | 78 kw (106 hp), Turbocharger | |
| Steering System | Steering Angle | ±36° |
| Min. Turning Radius | 3,660 mm | |
| System Pressure | 12 Mpa | |
| Axle | Brand | FEICHENG YUNYU |
| Main Transmission Type | Circular Arc Bevel Gear, Single Stage | |
| Wheel Side Reduction Type | Single Stage Planetary Type | |
| Torque Converter | Model | YJ280 |
| Type | Single-stage, Single-phase Three Element | |
| Cooling Type | Oil-cooling Pressure Circulation | |
| Gear Box | Type | Fixed Shaft Power Transmission |
| Gears | F2 + R2 | |
| Max. Speed | 25 km/h | |
| Tire | Model | 16/17-20 |
| Tire Pressure | F: 0.22 Mpa, R: 0.20 Mpa | |
| Brake System | Service Brake | Air Over Oil Caliper Brake, External Type, Self-adjustment, Self-balancing |
| Emergency Brake | Flexible Shaft Controlled Disc Brake | |
| Standard Configuration | Loader Bucket, Backhoe Bucket, Heater, Air Fan, Deluxe Adjustable Rotating Seat, New Luxury Interior Cab, Luxury Steering Wheel, Adjustable Instrument Panel, Hydraulic Joystick, 78kw Engine, 16/70-20 Tires, Special 280 Gearbox, Compact Articulated Chassis, Heavy-duty Large Wheel Side Axle, A-shaped or H-shaped Hydraulic Support Leg | |
Market Demand in Malaysia
Mr. Amir faced several challenges when searching for equipment:
- Variable Terrain Conditions
Projects across Malaysia span coastal areas, hilly zones, and urban regions, requiring equipment with excellent maneuverability. - Frequent Weather Changes
The monsoon season brings heavy rainfall, demanding stable operation even in muddy conditions. - Diverse Project Types
From trench excavation to material handling, he needed one machine to handle multiple operations. - Cost Control Pressure
As a mid-sized contractor, Amir needed to balance investment and returns — one reason he was interested in YG’s tractor loader backhoe for sale.
Decision to Choose YG Front End Loader Excavator
After evaluating several brands, Amir ultimately chose YG’s tractor loader backhoe for sale:
- Comprehensive Functional Configuration
The design concept of the front and back hoe loader perfectly matched his project requirements. - Outstanding Performance Parameters
Compared with other brands, YG equipment offered superior performance in key technical aspects. - Reliable Quality Assurance
The reinforced structure and high-quality components ensured dependable operation under harsh working conditions. - Complete After-Sales Service
The YG after-sales team is available 24/7, ensuring every customer enjoys efficient, caring, and reliable service support.
Value of Front End Loader Excavator in Application
The front and back hoe loader demonstrated excellent performance on site:
- Powerful and Efficient Hydraulic System
Thickened hydraulic cylinders combined with a 22Mpa system pressure ensured smooth digging even in hard soil. - Durable and Reliable Working Parts
A deeper and larger bucket made of reinforced material significantly extended the machine’s lifespan under sandy and gravel conditions. - Excellent Mobility
Engineering-grade tires and 300mm ground clearance allowed easy movement across muddy sites after heavy rain. - Flexible Functional Configuration
The quick-attach design enables the tractor front end loader backhoe to adapt to various working requirements. - User-Friendly Operation
Adjustable seats and an intuitive control system greatly reduce operator fatigue.
Customer Feedback and Project Results
After three months of use, Amir shared his experience:
- Significant Improvement in Efficiency
Compared to single-function machines, the front end loader excavator improved project efficiency by 40%. - Effective Cost Management
Low failure rate and fuel efficiency helped achieve better cost control. - Improved Project Quality
Precise operation enhanced accuracy and boosted client satisfaction. - Expanded Business Opportunities
Thanks to the multifunctional equipment, his company secured more diverse contracts.
Future Outlook and Cooperation
Based on the excellent performance of the first unit, Amir plans to continue purchasing YG equipment:
- Expanding Equipment Fleet
He intends to purchase two more units to meet growing business demand. - Deepening Cooperation
He hopes to establish a long-term partnership with YG to further develop the Malaysian market. - Technology Upgrades
He expressed strong interest in the new generation of tractor loader backhoe for sale, expecting more innovative features.
From a chance encounter in crisis to a trusted partnership today, YG’s front end loader excavator has proven its value through real-world performance. In Malaysia’s opportunity-rich market, this machine — blending innovative technology and practical design — is helping more contractors achieve breakthroughs in efficiency. As infrastructure development continues, the tractor front end loader backhoe is set to become the preferred choice for forward-thinking contractors.
In addition, YG Machinery also provides excavators, lifting platforms, spider cranes, and boom lifts. Contact us anytime for more product details and exclusive quotations!【WhatsApp/WeChat/Phone】+86 13837122632
