Electric Tank Dolly

Diesel tractors deliver strong power yet suffer from loud noise, black exhaust, and high fuel costs, facing stricter restrictions amid tightening environmental regulations. Forklifts are flexible but cannot access narrow aisles due to large turning radii. Manual rollers save money, yet they come with low efficiency, high safety risks, and shrinking labor availability. Is there equipment combining power and agility, quiet & clean operation, operable by a single person? The answer is yes — electric tank dolly. Equipped with dual-motor drive and remote control, it perfectly fills the gaps left by traditional transport methods.

Free Quote Now

Heavy-Duty Electric Load Moving Skate Tank Specifications

Item	10T	20T	25T	30T	40T	50T	60T
Motor	500W x2Brake-equipped 104Flange Reinforced Gearbox	750W x2Brake-equipped 104Flange Reinforced Gearbox	1000W x2Brake-equipped 104Flange Reinforced Gearbox	1200W x2 Brake-equipped 120 Flange Reinforced Gearbox	1500W x2Brake-equipped 120Flange Reinforced Gearbox	2000W x2Brake-equipped 120Flange Reinforced Gearbox	3000W x2Brake-equipped 120Flange Reinforced Gearbox
Controller	D2T80ADual Channel Driver	D2T80ADual Channel Driver	D2T100ADual Channel Driver	D2T100ADual Channel Driver	D2T200ADual Channel Driver	D2T200ADual Channel Driver	D2T220ADual Channel Driver
Remote Controller	C7 Remote Controller	C6/C7 Remote Controlleror Industrial Remote Controller	C7 Remote Controller	C7 Remote Controller	C6/C7 Remote Controlleror Industrial Remote Controller	C7 Remote Controlleror Industrial Remote Controller	C7 Remote Controlleror Industrial Remote Controller
Battery Spec.	48v 30AHTernary Lithium	48V 60AHTernary Lithium or Lithium Iron Phosphate	48V 60AHTernary Lithium or Lithium Iron Phosphate	48V 60AHTernary Lithium or Lithium Iron Phosphate	48V 120AHTernary Lithium or Lithium Iron Phosphate	48V 120AHTernary Lithium or Lithium Iron Phosphate	48V 120AHTernary Lithium
Operating Current	25A	60A	60A	60A	120A	120A	120A
Charging Current	54.6	54.6	54.6	54.6	54.6	54.6	54.6
Drive Wheel	80*120x4High Hardness Fully Imported Polyurethane	90x135x4High Hardness Fully Imported Polyurethane	90x135x4High Hardness Fully Imported Polyurethane	90x135x4High Hardness Fully Imported Polyurethane	140x140x4High Hardness Fully Imported Polyurethane	140x140x4High Hardness Fully Imported Polyurethane	140x140x8High Hardness Fully Imported Polyurethane
Gear	Luomengtai High-Strength Gear3-module	Luomengtai High-Strength Gear3-module	Luomengtai High-Strength Gear3-module	Luomengtai High-Strength Gear3-module	Luomengtai High-Strength Gear3-module	Luomengtai High-Strength Gear3-module	Luomengtai High-Strength Gear3-module
Steel Plate	10mmQ355 Manganese Steel Plate	10mmQ355 Manganese Steel Plate	12mmQ355 Manganese Steel Plate	12mmQ355 Manganese Steel Plate	16mmQ355 Manganese Steel Plate	16mmQ355 Manganese Steel Plate	16mmQ355 Manganese Steel Plate
Traction Weight	10T	20T	25T	30T	40T	50T	60T
Load Capacity	10T	10T	12.5T	15T	20T	25T	30T
Overall Dimension	500x550x145mm	670x620x165mm	670x635x165mm	740x640x185mm	810x800x182mm	810x800x182mm	1110x800x185mm
Flange Disc	Diameter 2900MM	Diameter 2900MM	Diameter 2900MM	Diameter 2900MM	Diameter 2900MM	Diameter 2900MM	Diameter 2900MM
Travel Speed	Adjustable: 2–10 m/min
Continuous Working Time	2–3 hours	3–4 hours	3–4 hours	3–4 hours	4–5 hours	4–5 hours	4–5 hours

Free Quote Now

Electric Tank Dolly vs Traditional Transport Solutions

Traditional heavy-load transportation mainly relies on three options: manual rollers, forklifts, and diesel towing equipment. Each method carries obvious drawbacks.

• In terms of safety, manual handling poses the highest risks. Minor shifting of dozens-ton equipment may lead to serious injury or fatal accidents. Although diesel equipment delivers strong power, operators must drive up close, exposing them to collision and crushing hazards. The electric tank dolly comes standard with an industrial wireless remote controller, offering a maximum control range of 100 meters. Operators remotely manage startup, movement, and speed to achieve man-machine separated operation. This is the core value of the remote control electric transporter concept — separate operators from heavy loads and eliminate safety risks at the source.
• The gap in operating costs is even more remarkable. Electric transport equipment consumes only 1–3 kWh per hour, with daily energy costs below $1.5. In contrast, diesel equipment costs roughly $20–25 for fuel over an 8-hour shift. For maintenance, the electric tank dolly has no complex engine or gearbox. Its annual maintenance expenses are over 60% lower than fuel-driven alternatives, saving hundreds of US dollars each year.
• Regarding noise reduction and zero emissions, it runs purely on electricity with no exhaust emissions and operating noise below 60 decibels. Diesel equipment generally exceeds 85 decibels and releases harmful fumes — unacceptable in enclosed workshops or environmentally sensitive sites.

Free Quote Now

Remote Control & Zero Turning Radius: How Electric Tank Dolly Masters Narrow Workshops

Older factories often feature narrow passages, dense equipment, and tight warehouse rack spacing — major pain points for traditional transport machines. Forklifts require large space for turning; overhead cranes are limited by fixed rails. Thanks to its 360° in-place rotation design, the equipment completely solves this problem.

The optimized chassis and omnidirectional wheel assembly enable in-place spinning without wide operating space. With a minimum turning radius of only 1.8 meters, it smoothly navigates gaps between machine tools and production lines, completing right-angle turns and relocation in tight work zones. This is what sets the electric load moving skate tank apart from conventional transport gear: it is not merely “able to turn”, but “turns anywhere”.

Daily Maintenance Checklist for electric load moving skate tank

The remote control electric transporter features a relatively simple structure, requiring far less routine maintenance than diesel machines. Below is a practical preventive maintenance checklist:

• Daily Inspection: Check battery level before and after use; confirm secure power cables; clean dirt and mud off the body.
• Weekly Maintenance: Inspect wheel condition for cracks or embedded debris; verify reliability and flexibility of steering assemblies.
• Monthly Service: Tighten battery terminals; check all component fasteners including wheel and steering bolts.
• Quarterly Service: Secure critical body bolts; add lubricant to drive gear assemblies and bearings.
• Semi-Annual Service: Full inspection of drive system; clean contaminants from electromagnetic brake friction plates.

Notably, YG units adopt Luomengtai high-strength gears. Precisely matched to motor power, reduction ratios, and load grades, they deliver low-speed high-torque output. These gears far outlast ordinary alternatives and reduce maintenance frequency further.

Free Quote Now

How Many Workers Can One Electric Tank Dolly Replace?

Purchasing one electric tank dolly requires upfront investment, yet the returns are substantial.

• Labor Savings: One remote control electric transporter replaces 2–3 skilled workers. Based on the average US manufacturing hourly wage of $26, labor expenses can be cut by approximately $1,200– $1,500 monthly.
• Energy Savings: Compared with diesel equipment, electric operation saves around $500– $600 in energy costs each month.
• Maintenance Savings: Annual maintenance costs drop by over 60% versus fuel machines, saving roughly $400–$600 every year.
• Productivity Gains: Transport efficiency increases more than 3 times versus traditional methods. For example, an auto parts factory used a remote control electric transporter to relocate 80-ton stamping equipment. A task originally taking two days was finished within four hours. Shorter production line downtime brings indirect benefits far exceeding the equipment price.

For enterprises with frequent transport tasks, the typical payback period is 6–12 months. After that, thousands of US dollars in operating costs can be saved annually.

Contact YG

If you struggle with heavy equipment relocation, hope to cut transport time from hours to dozens of minutes, or want one operator to handle dozens-ton loads — YG electric tank dolly is your ideal solution. Covering 10 tons to 60 tons, from workshops to docks, single-unit operation to multi-unit synchronized transport, YG delivers complete heavy transport solutions. As a heavy-duty electric load moving skate tank, it is built for harsh working conditions with reliable load capacity and flexible control.

Call YG hotline or visit our official website for full product details. Professional engineers will recommend the optimal model according to your actual working conditions. Let it become your reliable transport assistant and simplify heavy-load moving forever.
