If you are looking for reliable heavy-duty handling equipment for factories, warehouses, or construction sites, you may face a wide range of options. Can it carry sufficient load? What is the remote control distance? How long will the battery last? These are key factors to consider during selection. The electric tank transporter is a product line developed by YG specially for heavy-load handling scenarios, covering multiple models from 10 tons to 60 tons. It has passed tests on numerous projects across Colombia.
Electric Tank Transporter Specifications
| Model | 10T | 20T | 25T | 30T | 40T | 50T | 60T |
| Motor | 500W x2Brake-equipped 104Flanged Reinforced Gearbox | 750W x2Brake-equipped 104Flanged Reinforced Gearbox | 1000W x2Brake-equipped 104Flanged Reinforced Gearbox | 1200W x2Brake-equipped 120Flanged Reinforced Gearbox | 1500W x2Brake-equipped 120Flanged Reinforced Gearbox | 2000W x2Brake-equipped 120Flanged Reinforced Gearbox | 3000W x2Brake-equipped 120Flanged Reinforced Gearbox |
| Controller | D2T80ADual Drive Controller | D2T80ADual Drive Controller | D2T100ADual Drive Controller | D2T100ADual Drive Controller | D2T200ADual Drive Controller | D2T200ADual Drive Controller | D2T220ADual Drive Controller |
| Remote Controller | C7 Remote Controller | C6/C7 Remote Controlleror Industrial Remote Controller | C7 Remote Controller | C7 Remote Controller | C6/C7 Remote Controlleror Industrial Remote Controller | C7 Remote Controlleror Industrial Remote Controller | C7 Remote Controlleror Industrial Remote Controller |
| Battery Spec. | 48V 30AHTernary Lithium | 48V 60AHTernary Lithium or LFP | 48V 60AHTernary Lithium or LFP | 48V 60AHTernary Lithium or LFP | 48V 120AHTernary Lithium or LFP | 48V 120AHTernary Lithium or LFP | 48V 120AHTernary Lithium |
| Working Current | 25A | 60A | 60A | 60A | 120A | 120A | 120A |
| Charging Current | 54.6A | 54.6A | 54.6A | 54.6A | 54.6A | 54.6A | 54.6A |
| Drive Wheels | 80*120×4High-hardness Fully Imported Polyurethane | 90×135×4High-hardness Fully Imported Polyurethane | 90×135×4High-hardness Fully Imported Polyurethane | 90×135×4High-hardness Fully Imported Polyurethane | 140×140×4High-hardness Fully Imported Polyurethane | 140×140×4High-hardness Fully Imported Polyurethane | 140×140×8High-hardness Fully Imported Polyurethane |
| Gear | Luomengtai High-strength Gear3-Module Design | Luomengtai High-strength Gear3-Module Design | Luomengtai High-strength Gear3-Module Design | Luomengtai High-strength Gear3-Module Design | Luomengtai High-strength Gear3-Module Design | Luomengtai High-strength Gear3-Module Design | Luomengtai High-strength Gear3-Module Design |
| Steel Plate | 10mmQ355 Manganese Steel Plate | 10mmQ355 Manganese Steel Plate | 12mmQ355 Manganese Steel Plate | 12mmQ355 Manganese Steel Plate | 16mmQ355 Manganese Steel Plate | 16mmQ355 Manganese Steel Plate | 16mmQ355 Manganese Steel Plate |
| Towing Capacity | 10T | 20T | 25T | 30T | 40T | 50T | 60T |
| Loading Capacity | 10T | 10T | 12.5T | 15T | 20T | 25T | 30T |
| Overall Dimension | 500×550×145mm | 670×620×165mm | 670×635×165mm | 740×640×185mm | 810×800×182mm | 810×800×182mm | 1110×800×185mm |
| Rotary Flange | Φ2900mm | Φ2900mm | Φ2900mm | Φ2900mm | Φ2900mm | Φ2900mm | Φ2900mm |
| Travel Speed | Adjustable: 2–10 m/min | Adjustable: 2–10 m/min | Adjustable: 2–10 m/min | Adjustable: 2–10 m/min | Adjustable: 2–10 m/min | Adjustable: 2–10 m/min | Adjustable: 2–10 m/min |
| Continuous Working Time | 2–3 hours | 3–4 hours | 3–4 hours | 3–4 hours | 4–5 hours | 4–5 hours | 4–5 hours |
Case 1: Handling Upgrade for Machinery Manufacturing Plant in Bogotá
Client Requirement
In early 2025, a medium-sized machinery manufacturing plant with over 200 employees in Bogotá contacted YG. The factory mainly produces large agricultural machinery components. It frequently moves metal blanks and finished products weighing 3 to 15 tons inside the workshop. Previously, they used forklifts combined with manual pallet trucks for transportation. However, narrow workshop aisles made forklift turning difficult. Meanwhile, exhaust fumes and noise from diesel forklifts seriously worsened the working environment. The client needed equipment that can flexibly steer in tight spaces, support remote control, and handle heavy workpieces above 10 tons.
YG Solution
Based on on-site survey data, the YG technical team recommended the electric tank transporter 30T model (15-ton loading capacity, 30-ton towing capacity). This unit is equipped with dual 1200W motors and Luomengtai high-strength gears to deliver low-speed high torque, ensuring stable and powerful operation under full load. The 360° wireless remote steering system allows operators to control directions precisely from a safe distance. Four 90×135mm high-hardness imported polyurethane drive wheels operate smoothly on factory concrete floors without surface damage.
Project Process
After three video conferences and one on-site working condition video recording, YG finished customized drawings and a quotation within two weeks. After comparing multiple suppliers, the client chose YG thanks to comprehensive advantages in load capacity, remote control system, and battery endurance. The contract was signed in March 2025. Production and factory testing were completed in April, and the unit was shipped to Colombia via Cartagena Port in May.
Operation Result
Three months after commissioning, the client reported: The electric tank transporter cut the average inter-workshop transportation time of heavy workpieces from 25 minutes to 12 minutes, lifting efficiency by more than 50%. Transport work that originally required 3 workers can now be completed by one person with remote control, cutting labor costs by roughly 65%. No more diesel exhaust inside the workshop; air quality improved significantly, and worker satisfaction increased greatly.
Case 2: Cargo Handling Innovation for Logistics Warehouse in Medellín
Client Requirement
In the second half of 2025, a logistics and warehousing center serving local coffee and agricultural export businesses in Medellín sent an inquiry to YG. The warehouse covers around 5,000 m² and processes large volumes of goods loaded on heavy pallets every day. Single cargo weight ranges from 5 to 25 tons. They needed a heavy-duty remote control tank transporter that can travel flexibly inside the warehouse and provide sufficient traction to move fully loaded cargo pallets.
YG Solution
YG recommended the electric tank transporter 50T model (25-ton loading capacity, 50-ton towing capacity). It adopts dual 2000W motors, a 48V 120AH large-capacity battery (4–5 hours continuous runtime), and a 16mm Q355 manganese steel frame, guaranteeing stability and durability during intensive continuous shifts. It is fitted with an industrial-grade C7 remote controller with a stable signal and sensitive operation. Operators can remotely control the unit safely from 20 meters away. The 360° anti-slip threaded rotary plate with built-in ball bearings delivers smooth steering, enabling easy U-turns even in densely packed warehouse aisles.
Project Process
In August 2025, the client sent detailed warehouse layout drawings and handling requirements; YG provided a complete solution and quotation. During communication, the client paid special attention to battery endurance and charging convenience. The heavy-duty electric load moving skate tank from YG uses a 48V lithium battery and supports fast charging. A full charge enables 4–5 hours of continuous operation, fully meeting the handling demand for one working shift. After two rounds of technical confirmation, the contract was signed in September. The equipment arrived at the Medellín warehouse and finished on-site commissioning in November.
Operation Result
Data provided by the warehouse after two months of operation shows: The remote control electric transporter boosted heavy cargo handling efficiency by approximately 60%, lifting daily pallet throughput from 80 units to 130 units. Zero equipment failure was recorded, bringing extremely low maintenance costs. Electric drive greatly reduces warehouse noise and significantly improves operator comfort. The warehouse operations manager commented that this heavy-duty electric load moving skate tank has become the “most reliable core equipment” for daily operations.
Contact YG
From machinery workshops in Bogotá to logistics warehouses in Medellín, YG electric tank transporter helps more and more Colombian enterprises achieve major improvements in handling efficiency. We supply seven models covering 10 tons to 60 tons load capacity. All units adopt Luomengtai high-strength gears, Q355 manganese steel frames, and high-hardness imported polyurethane wheels to deliver long service life in all kinds of industrial environments.
Whether you operate factory workshops, construction sites, ship terminals, or logistics warehouses, if you have heavy-load handling demands, YG can provide professional and reliable heavy-duty remote control tank transporter solutions. Feel free to contact us for detailed product brochures and customized quotations. Let YG electric tank transporter become your powerful assistant to boost handling efficiency.
